Don’t forget the hoisting rope to get the wire antenna up there!  Visit our rope page for suitable rope.

Alpha Delta DX series HF wire antennas are unique in the industry, using severe weather rated components for extreme environments such as high tensile strength insulated solid copper 12 Ga. wire, and stainless steel hardware. Many models use internal gas tube static voltage protectors. The Model DX series has the most efficient performance we have tested----better than metal enclosed trap types or end-fed half wave models. The difference can be significant!  Features:








Interested in other models or band combinations?  Email for more details on other models available, Chris at KF7P dot com.




Installs as inverted vee or dipole.  Covers 40, 20, 15, and 10 meters and 30, 17, and 12 with your tuner.  Length is 40 feet.  Power rating is 1kw CW/PEP.


This item ships direct from Alpha Delta.

Installs as inverted vee or dipole.  Covers 160, 80, 40, 20, 15, and 10 meters.  Length is 100 feet.  Power rating:  160 and 80 meters: 600 watts CW/PEP.  1kw CW/PEP remaining bands.


This item ships direct from Alpha Delta.

Installs as inverted vee or dipole.  Covers 80, 40, 20, 15, and 10 meters and 30, 17, and 12 with your tuner.  Length is 82 feet.  Power rating is 1kw CW/PEP.


This item ships direct from Alpha Delta.

Models below are “fan dipole” style wire antennas, as shown in the 1/4 scale model above (but the coils and center insulator are full size).

ISO-Res™ loading coils are high-Q and very efficient and made from weather-stable materials for long life, as are the wire spacers.  Coils are coated in a UV protective coating for long life.  No traps or capacitors that can break down under high RF voltages are used!

All Alpha Delta antennas use direct 50 ohm feed for easy assembly and immediate use!  Center insulator made from Deltalloy™, an indestructible high impact plastic with excellent UV resistance and RF insulation properties.  All hardware is stainless steel.

  1. No-trap design

  2. Stainless steel hardware

  3. Fully assembled

  4. Severe weather and UV rated

  5. Made in Alpha Delta’s ISO 9001 certified production facility.

Typical installation in inverted vee configuration using tall center support.  Flat top dipole installations are also good.

Price:        $159.95

Price:        $209.95

Price:        $179.95

              WIRE ANTENNAS
Model DX EE   40m-20m-15m-10m
Model DX LB Plus   160m-80m-40m-20m-15m-10m
Model DX CC  80m-40m-20m-15m-10m

Be the first to review this product!!!

User Reviews:  What are other hams saying about these products?

*****

*****

Pulley with quick link.




Price:  $4.95

User Reviews:  What are other hams saying about these products?
OPTIONAL ACCESSORIES

Stainless steel “stealth” pulley, great for your “invisible” wire antennas!  Small 1” sheave and stainless steel frame.  Good for 3/32” to 3/16” rope.

Price:  $5.00

STEALTH

OUT OF STOCK
